Schneider Electric Harmony Relay Series Solid State Relay, 3.5 A Load, PCB Mount, 24 V dc Load, 30 V dc Control

View all Solid State Relays

Subtotal (1 unit)*

HK$150.70

Add to Basket
Select or type quantity
In Stock
  • 59 unit(s) ready to ship from another location
  • Plus 58 unit(s) shipping from 28 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +HK$150.70

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:
922-1837
Distrelec Article No.:
304-11-446
Mfr. Part No.:
SSL1D03BD
Manufacturer:
Schneider Electric
Find similar products by selecting one or more attributes.
Select all

Brand

Schneider Electric

Maximum Load Current

3.5 A

Mounting Type

PCB Mount

Maximum Load Voltage

24 V dc

Minimum Load Voltage

1 V dc

Minimum Control Voltage

15 V dc

Maximum Control Voltage

30 V dc

Switching Type

DC

Control Voltage Range

15 → 30 V dc

Minimum Load Current

0.001 A

Number of Poles

1

Terminal Type

PCB Pin

Contact Configuration

SPST

Output Device

MOSFET

Relay Type

Single Phase

Load Voltage Range

1 → 24V dc

Maximum Turn On Time

0.35ms

Series

Harmony Relay

Better World Product

Yes

Better World Verification

Green Premium

Dimensions

28 x 5 x 15mm

Length

28mm

Off State Leakage Current

0.001 mA

Height

15mm

Operating Temperature Range

-20 → +80°C

Depth

5mm

Capacitance

1.5pF

Standards Met

CE, CSA, UL

Special Features

Built-In Diode Protection Circuit & LED Indicator, Mounted on Universal AC/DC Sockets, Slim Interface SSL Relays with PCB Terminals

RoHS Status: Exempt

COO (Country of Origin):
MX

Zelio SSL Solid State Slim Relays


Schneider Electric Zelio solid state relays provide a compact and innovative solution for a wide variety of applications with interfacing control and load switching. The slim SSL series are available with several input and output configurations for both AC and DC switching applications. Compact size and modular design reduces space and allows easy mounting on the socket.
SSL series plug-in type relays can be mounted directly on a PCB or DIN Rail mounted with a socket. DIN Rail sockets are available in screw connector or spring terminal types.

Zero voltage switching or Random switching
Easy maintenance
High switching frequency
Resistance to shock, vibration and contamination
Long life span

Schneider Electric SSL1D03BD


This Harmony SSL slim interfacing solid state plug-in relay is rated 3.5A, is controlled with a 15V to 30V DC input, has a rated load voltage of 1V to 24V DC with DC switching. It is 6mm width, including socket, to save space in your control cabinets. It is also silent and reliable thanks to the absence of moving contacts. It is shock, vibration and pollution resistant thanks to its IP67, it makes it ideal for harsh industrial environments.
