i-Autoc Panel Mount Solid State Relay, 60 A Max. Load, 530 V ac Max. Load, 32 V dc Max. Control

RS Stock No.:: 164-0572
Mfr. Part No.:: KSI480D60-L
Manufacturer:: i-Autoc

i-Autoc Panel Mount Solid State Relay, 60 A Max. Load, 530 V ac Max. Load, 32 V dc Max. Control

On back order for despatch 13/06/2023, delivery within 3 working days

Added

Price Each

Was HK$415.36

You pay

HK$353.06

units	Per unit
1 +	HK$353.06

RS Stock No.:: 164-0572
Mfr. Part No.:: KSI480D60-L
Manufacturer:: i-Autoc

COO (Country of Origin):: CN

Product overview and Technical data sheets

Datasheet

Build or Request PCB Symbol & Footprint

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

KSI series single phase solid state relay use the Triac or SCR output. It is widely used in various industry applications, and it can be used for the resistive, inductive or capacitive loads. The control voltage is 4-32VDC or 90-280VAC, load voltage is 240VAC, 380VAC, 480VAC or 600VAC. Wide load current range from 10 to 125A.

Zero crossing or Random-on
Load current:10A-125A @48-660VAC
TRIAC or SCR output
AC or DC control
Dielectric strength ≥4000VACrms
LED indicator
Build-in MOV or TVS option

Specifications

Attribute	Value
Maximum Load Current	60 A
Mounting Type	Panel Mount
Series	KSI
Minimum Load Voltage	48 V ac
Maximum Load Voltage	530 V ac
Minimum Control Voltage	4 V dc
Maximum Control Voltage	32 V dc
Switching Type	Zero Cross
Terminal Type	Screw
Output Device	SCR, TRIAC
Maximum Turn On Time	10ms
Load Voltage Range	48 → 530V ac
Control Voltage Range	4 → 32 V dc
Relay Type	Single Phase
Dimensions	58.4 x 45.7 x 20.5mm
Off State Leakage Current	5 mA
Length	58.4mm
Maximum Operating Temperature	+80°C
Height	20.5mm
Minimum Operating Temperature	-30°C
Operating Temperature Range	-30 → +80°C
Special Features	Build-In MOV/TVS Option, DC Control, Dielectric Strength, LED Indicator, TRIAC or SCR Output
Standards Met	CCCs, CE, CULus, TUV
Depth	45.7mm
