Molex C-Grid III Series Vertical Through Hole PCB Header, 8 Contact(s), 2.54 mm Pitch, 2 Row, Unshrouded

RS Stock No.:: 360-6487
Mfr. Part No.:: 90131-0764
Manufacturer:: Molex

Molex C-Grid III Series Vertical Through Hole PCB Header, 8 Contact(s), 2.54 mm Pitch, 2 Row, Unshrouded

The image is for reference only, please refer to product details and specifications

Bulk discount available

Subtotal (1 pack of 5 units)*

HK$82.60

FREE delivery for orders over HK$250.00

In Stock

555 unit(s) ready to ship from another location
Plus 15 unit(s) shipping from 22 December 2025

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Pack*
5 - 20	HK$16.52	HK$82.60
25 +	HK$13.60	HK$68.00

*price indicative

RS Stock No.:: 360-6487
Mfr. Part No.:: 90131-0764
Manufacturer:: Molex

Specifications

Product overview and Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Molex
	Product Type	PCB Header
	Series	C-Grid III
	Current	3A
	Pitch	2.54mm
	Number of Contacts	8
	Housing Material	Polyester
	Number of Rows	2
	Orientation	Vertical
	Shrouded/Unshrouded	Unshrouded
	Connector System	Wire-to-Board
	Mount Type	Through Hole
	Contact Material	Brass
	Contact Plating	Gold
	Termination Type	Solder
	Row Pitch	2.54mm
	Minimum Operating Temperature	-55°C
	Contact Gender	Male
	Tail Pin Length	2.9mm
	Maximum Operating Temperature	125°C
	Mating Pin Length	6.75mm
	Standards/Approvals	No
	Voltage	350 V
	Distrelec Product Id	304-41-779

	Select all
	Brand Molex
	Product Type PCB Header
	Series C-Grid III
	Current 3A
	Pitch 2.54mm
	Number of Contacts 8
	Housing Material Polyester
	Number of Rows 2
	Orientation Vertical
	Shrouded/Unshrouded Unshrouded
	Connector System Wire-to-Board
	Mount Type Through Hole
	Contact Material Brass
	Contact Plating Gold
	Termination Type Solder
	Row Pitch 2.54mm
	Minimum Operating Temperature -55°C
	Contact Gender Male
	Tail Pin Length 2.9mm
	Maximum Operating Temperature 125°C
	Mating Pin Length 6.75mm
	Standards/Approvals No
	Voltage 350 V
	Distrelec Product Id 304-41-779

Molex C-Grid III Series PCB Header, 2.54mm Pitch, 8 Contacts - 90131-0764

This PCB header is a C-Grid III connector designed for versatile applications within the electronics sector. With a pitch of 2.54mm, it features a dual-row layout accommodating 8 circuits and operates with a vertical orientation. This through-hole PCB header is constructed from durable brass and features a gold-plated finish for enhanced conductivity.

Features & Benefits

• 8 contact PCB header ensures reliable connections

• 3A current rating supports various low-power applications

• 350V voltage rating enhances durability in demanding environments

• Vertical design facilitates space-efficient circuit layouts

• Unshrouded connectors simplify component placement

• Compatibility with wire-to-board configurations for enhanced versatility

Applications

• Utilised in automation and control systems

• Ideal for electronic devices requiring reliable signal connections

• Employed in industrial machinery for robust wiring solutions

• Suitable for custom circuit board designs in varied environments

What is the significance of the gold plating in the connector?

Gold plating improves conductivity and resistance to corrosion, ensuring long-lasting performance and reliability in signal transmission.

How does the vertical orientation benefit circuit design?

The vertical orientation allows for compact arrangements, making it easier to fit within tight spaces and enabling efficient board layout designs.

Is the connector suitable for high-temperature applications?

Yes, it operates within a temperature range from -55°C to +125°C, making it suitable for diverse settings, including high-temperature environments.

Can this header be used for both signal and power transmission?

Yes, it serves effectively for both signal and low-power transmission applications, providing flexibility in circuit design.

What is the maximum process temperature for soldering?

The header can withstand a maximum process temperature of 230°C during soldering, ensuring reliable installation.

Molex C-Grid III 2.54 mm PCB Pin Headers - 90120, 90121, 90122 and 90131 Series

90120, 90121, 90122 and 90131 series PCB headers that form part of the 2.54 mm C-Grid III interconnection system designed to meet the latest industry requirements. These C-Grid III PCB headers mate with C-Grid III series PCB sockets and crimp housings for use in both board to board and wire to board applications. The headers have a breakaway design and can be cut to size for additional design flexibility. The pins of these PCB pin headers have a high retention force for a secure mating connection. The contacts, once soldered to the PCB also have a high mechanical stability. These 2.54 mm C-Grid PCB pin headers are available in single and dual row, vertical and right angle mounting configurations to suit a range of interconnection requirements.

Features and Benefits

• Suitable for use in board to board and wire to board applications

• Breakaway feature for design flexibility

• High pin retention force for secure mating connection

• High mechanical stability once soldered

Product Application Information

C-Grid III series connectors are suitable for use in the industrial, computer, medical, consumer, telecommunications and transportation industry. Applications include Desktop PCs, servers, monitors, medical equipment, white goods, exchange stations, industrial equipment and automotive safety systems and electronics.

2.54mm Molex C-Grid III Range

Standards

DIN 41651; HE13/14
