Relpol PCB Mount Power Relay, 12V dc Coil, 5A Switching Current, SPST
- RS Stock No.:
- 134-8391
- Mfr. Part No.:
- RM32N-3021-85-1012
- Manufacturer:
- Relpol
Subtotal (1 unit)**
HK$38.40
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over HK$250.00
Units | Per unit |
|---|---|
| 1 - 4 | HK$38.40 |
| 5 + | HK$34.50 |
**price indicative
- RS Stock No.:
- 134-8391
- Mfr. Part No.:
- RM32N-3021-85-1012
- Manufacturer:
- Relpol
Select all | Attribute | Value |
|---|---|---|
| Brand | Relpol | |
| Coil Voltage | 12V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 5A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 277V | |
| Maximum Switching Voltage DC | 28V dc | |
| Length | 18.8mm | |
| Coil Resistance | 320Ω | |
| Coil Power | 450mW | |
| Isolation Coil To Contact | 2.5kV ac | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | -40°C | |
| Contact Material | Silver Alloy | |
| Height | 15.3mm | |
| Depth | 10.6mm | |
| Life | 100000 (Electrical) cycles, 10000000 (Mechanical) cycles | |
| Maximum Switching Power DC | 186 W | |
| Maximum Switching Power AC | 1.25 kVA | |
| Application | Automation Systems, Electrical Equipment, Household Electrical Appliance, Instrument & Meter, Lighting Controls, Remote Control Facilities, Telecommunications Equipment | |
