STMicroelectronics Surface Mount Chip Balun
- RS Stock No.:
- 192-4673
- Mfr. Part No.:
- BAL-UWB-01E3
- Manufacturer:
- STMicroelectronics
On back order for despatch 27/01/2025, delivery within 3 working days
Added
Price Each (On a Reel of 5000)
HK$2.636
| Units | Per unit | Per Reel* |
| 5000 - 20000 | HK$2.636 | HK$13,180.00 |
| 25000 + | HK$2.583 | HK$12,915.00 |
| *price indicative | ||
- RS Stock No.:
- 192-4673
- Mfr. Part No.:
- BAL-UWB-01E3
- Manufacturer:
- STMicroelectronics
Product overview and Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The BAL-UWB-01E3 is an ultra-miniature balun that integrates matching network, dedicated to ultra-wide band 3 GHz to 8 Ghz. This device uses STMicroelectronics IPD technology on non conductive glass substrate which optimizes RF performance.
Very low profile
High RF performance
PCB space saving
Efficient manufacturability
LGA footprint compatible
Low thickness ≤ 450 μm
High RF performance
PCB space saving
Efficient manufacturability
LGA footprint compatible
Low thickness ≤ 450 μm
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Maximum Insertion Loss | 1.2dB |
| Mounting Type | Surface Mount |
| Pin Count | 6 |
| Length | 1.825mm |
| Maximum Frequency | 8GHz |
| Maximum Operating Temperature | +105°C |
| Minimum Operating Temperature | -40°C |
