onsemi NFAP0560L3TT Smart Power Module 600 V, 29-Pin SIP
- RS Stock No.:
- 229-6436P
- Mfr. Part No.:
- NFAP0560L3TT
- Manufacturer:
- onsemi
118 In stock for delivery within 3 working days
Added
Price Each (Supplied in a Tube)
HK$95.70
| Units | Per unit |
| 10 - 19 | HK$95.70 |
| 20 - 49 | HK$92.73 |
| 50 - 99 | HK$90.76 |
| 100 + | HK$88.80 |
- RS Stock No.:
- 229-6436P
- Mfr. Part No.:
- NFAP0560L3TT
- Manufacturer:
- onsemi
Product overview and Technical data sheets
Legislation and Compliance
Product Details
The ON Semiconductor fully-integrated inverter power stage consisting of a high-voltage driver, six IGBT’s and a thermistor, suitable for driving permanent magnet synchronous motors, brushless- DC motors and AC asynchronous motors. The IGBT’s are configured in a 3-phase bridge with separate emitter connections for the lower legs for maximum flexibility in the choice of control algorithm.
High precision monitor is possible
A single power supply drive is enabled through the use of bootstrap circuits for upper power supplies
Built-in under voltage protection
Compact size help to reduce PCB size
A single power supply drive is enabled through the use of bootstrap circuits for upper power supplies
Built-in under voltage protection
Compact size help to reduce PCB size
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Maximum Collector Emitter Voltage | 600 V |
| Number of Transistors | 6 |
| Maximum Power Dissipation | 12 W |
| Package Type | SIP |
| Channel Type | N |
| Pin Count | 29 |
| Transistor Configuration | Series |
