Texas Instruments CD4046BE, PLL Circuit 1 18 V 16-Pin PDIP
- RS Stock No.:
- 923-6693
- Mfr. Part No.:
- CD4046BE
- Manufacturer:
- Texas Instruments
The image is for reference only, please refer to product details and specifications
On back order for despatch 03/06/2024, delivery within 3 working days
Added
Price Each (In a Tube of 25)
HK$5.612
| Units | Per unit | Per Tube* |
| 25 - 25 | HK$5.612 | HK$140.30 |
| 50 - 75 | HK$5.443 | HK$136.075 |
| 100 + | HK$5.28 | HK$132.00 |
| *price indicative | ||
- RS Stock No.:
- 923-6693
- Mfr. Part No.:
- CD4046BE
- Manufacturer:
- Texas Instruments
Product overview and Technical data sheets
Legislation and Compliance
Product Details
4000 Series Complex Function, Texas Instruments
Texas Instruments Complex Function ICs from the 4000 Series CMOS Logic Family includes 7-segment LCD Latch/Decoder/Drivers, Magnitude Comparators and Phase Locked Loop (PLL) ICs.
4000 CMOS Logic Family, Texas Instruments
CMOS Family devices
Wide operating voltage range: 3 to 18V
Wide operating voltage range: 3 to 18V
Specifications
Attribute | Value |
|---|---|
| Number of Elements per Chip | 1 |
| Mounting Type | Through Hole |
| Package Type | PDIP |
| Pin Count | 16 |
| Dimensions | 19.3 x 6.35 x 4.57mm |
| Height | 4.57mm |
| Length | 19.3mm |
| Maximum Operating Supply Voltage | 18 V |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Supply Voltage | 3 V |
| Minimum Operating Temperature | -55 °C |
| Width | 6.35mm |
